m44t
★input/ output input channel: m44t(4ch) output channel: m44t(4ch) input impedance:＞10kω output impedance:50ω max.level: 20dbu mode:electronic balance | ★front panel figuration monitor: two line 20 character backlight lcd electronical level: 7-bit led the key: 8 mute button 8 channel selection button 3 menu button 3 parameter control button | ★adjustable parameters master gain:-12 to 12db, 0.1db stepping channel gain: -18 to 0 db, 0.1db stepping phase：0°or 180° delay: each input/output max.850ms eq：each input/output,5xeq eq types: peq, hp, lp, shelv, aull pass, band pass, trapper eq gain：-15 to 15db, 0.5db stepping eq bandwidth: 0.009 to 4.8 octaves (q=0.3 to 20) |
★analog audio frequency response： /- 1db (20 to 20khz) snr：92db typical (a weigkted) cmrr: > 40db (20 to 10khz) crosstalk：< -100db distortion：0.005% (1khz @0dbu) | ★connector analog audio input/output: 3pin xlr usb connector: type b network connector:2×rj45 connector (tcp/ip&m-lan) maximum distance: cat 5e within 100 meters digital audio output connector: s/pdif power: socket with iec standard | ★frequency separating filter filter type：butterworth, bessel, linkwitz riley the slope: 6 to 48db/oct，and user defined ★ rms limiter threshold:-10 to 20dbu compression ratio: 1:1 to 32:1 soft/hard turning point：0% to 100% attack time: 5 to 200ms release time: 0.1s to 3s |
★digital audio dsp：24bits sampling rate：48khz adc/dac：24bits 192khz high-resolution chip transmission delay：1.27ms | ★general specification power：90-265 vac (50 / 60hz) dimension：19"x1.75"x9"(483x44x229mm) weight：10 lbs / 4.6 kg ★ signal input type analog/digital | ★peak limiter threshold: -10 to 20dbu attack time: 5 to 200ms release time: 0.1s to 3s |
