pl-575 computer moving head pattern light

和记娱乐手机app的产品展示图 pla谱莱声 工程产品 pl-575 电脑摇头图案灯.jpg

technology parameter


input voltage: ac 100-240v, 50 / 60hz



ballasts: inductance ballast



light source: philips msr 575/2 mini fastsit, color temperature 7200k,  life expectancy1000hours



color wheel ι: 9 discs white light, adjustable speed and rainbow effect



color wheel п: 9 discs white light, 3200k and 5600k color temperature converter



gobo wheel ι: 6 rotatable pattern white light,two-way rotation



gobo wheel п: 9 patterns white light, shaking and rotation effect



focus: 0 to 100% linearly focus



prism: 3-facet prism rotating in both directions,positioning function



dimmer: two-plate dimming, 0 to 100%  linearly adjustable



strobe: adjustable speed( 0.3 to 10 times/s), double guillotine/shading



display: 4-bits led, adjust address, special function and effect regulation



beam angle: parallel beam, 18° view angle



head movement: pan 540°, tilt 270° with auto position correction


control : 3 pins and 5 pins dmx512 interface



protocol: usitt-dmx-512



channels: 16/14 channels



net weight: 34kgs



gross weight: 36kgs



size: 54×53×66 cm



channel form

formal mode

function

ch1

pan

ch2

the level of micro step

ch3

tilt

ch4

the vertical of micro step

ch5

p/t speed

ch6

switch

ch7

color wheel ι

ch8

color wheel п

ch9

prism

ch10

fixed gobo wheel

ch11

rotatable gobo wheel

ch12

rotating pattern index

ch13

aperture value

ch14

focus

ch15

shading/stroboscopic

ch16

dimmer
